Columbia Manhattanville





Electrical Controls
Electrical supply delivered directly by ConEdison is monitored through the BMS to meter the electrical feed that serves the CoGen plant.
Network & Integration Controls
Provide a Distribution Control System Network Topology consisting of a 12 strand fiber network, workstations, DCS Control Panels, Network servers and remote I/O control panels that runs on Allen Bradley System.
Chilled Water Systems
Third party protocol integrates with the chiller plant that contains several cooling tower cells, and condenser water system that works with primary chilled and condenser water pumps to adequately supply campus.
Steam & Hot Water Systems
Sophisticated boiler enabled with set point system in place that effectively monitors the flow pressure and adaquate temperature required.
Cool Air Controls
Numerous AHU's and exhaust fans serve the facility as well as the multiple mechanical rooms to maintain proper air quality throughout.
Stony Brook University West Plant





Chilled Water Systems
Through turbine and electrical chillers, the chilled water is utilized on campus to provide central air-conditioning thought the campuses academic buildings.
Steam & Hot Water Systems
Newly installed boilers and two cascade heaters help provide an efficient amount of hot water at approximately 350°F, that's required for the steam and water supply.
Heat Applications
Additionally, the steam is also used to drive steam turbines, which are connected to the large chillers that produce the required chilled water supply.
Network & Integration Controls
Rockwell's Allen Bradley controllers and Rosemount devices work seamlessly through the custom built BMS to not only provide real-time data but also to work immediately with commands.
Electrical Controls
Electrical switchgear composed of set points to monitor the main disturbed power required for day-to-day operational loads.
1 Bryant Park




Sustainable Applications
4.6 Megawatt CoGen plant in place to create sustainable power to efficiently supply the buildings energy and heating requirements by up to 65% of the annual usage.
Chilled Water Systems
One 1200 and two 1000 ton electric drive chillers establish a sophisticated cooling system that helps to feed the ice storage system that enables the tower for free cooling mode when applicable conditions apply.
Electrical Controls
Remaining electricity stored from the CoGen is utilized for producing the supply for the ice storage system, which is then melted throughout the day to supply the demand for cooling the multiple office spaces.
Network & Integration Controls
Remaining electricity stored from the CoGen is utilized for producing the supply for the ice storage system, which is then melted throughout the day to supply the demand for cooling the multiple office spaces.
250 Vesey Street




Cool Air Controls
Coil units on all tenant floors are monitored to assure the air pressure, temperature and humidity levels are running to maintain a comfortable atmosphere.
Sustainable Applications
The energy sustainable central cooling plant utilizes river water that provides direct cooling supply for up to four months throughout the year by cycling through the cooling tower plant. Installed devices help to monitor these running conditions through the BMS for advanced trending and data results.
Steam & Hot Water Systems
Within the building are high efficiency pressure-steam systems that supply the secondary water loops that serve the shell and tube heat exchangers to adequately serve up the buildings perimeter heating fan power boxes.
Network & Integration Controls
Navigable easy-to-use screen help optimize and enhance the way the engineers and staff benchmark data and trends. This enables them to find new opportunities in the BMS for running cost and energy savings.
WE TAKE OUR SERVICES TO THE
EDGE:
Efficient Design
Dedicated to Our Clients
Ground Breaking Mentality
Energetic Focus
We design to provide the services & tools needed for our clients to operate in a way that no one else can do.
SCROLL TO START
We Make New Solutions Possible

BUILDING MANAGEMENT SYSTEMS

SUSTAINABLE ENERGY

CRITICAL SYSTEMS

First-Rate SERVICE DEPARTMENT








OUR ALL-IN-ONE PLATFORM, FACILITYVIEW™
UNPARALLED CREATIVITY
REAL-TIME DATA & TRENDS
CROSS-PLATFORM
INTELLIGENT STRATEGIES
Our designers recognize and create compelling solutions to client’s ideas that assist them in solving problems through facility needs under one secure and collaborative interface.
We have been standardizing the use of protocols through our BMS integration to provide our clients with resourceful information logs so they can make useful changes to their facilities running operations.
The intuitive BMS workstations provide you with the customization tools needed to control your facility with a click of a mouse, a swipe of a tablet or a tap of an app. Our staff is on standby ready to answer any and all questions that may arise.
Outlining risk and opportunities through our designs guarantee your facilities BMS the power to control all fluctuating aspects that tie in a complete controls interface. Our teams of engineers diligently apply methods that solve industry problems.
